SAT C35|35 DB PRO Offset CX/Gravel Wheelset
Regular price €879,00
Unit price per
Colore decalcomania: Nero lucido
Finitura trama: Marmo opaco
Materiale dei cerchi: Fibra di carbonio T800 SENZA traccia dei freni
Tipo di cerchi: Clincher/Tubeless
Profondità cerchi: 35 mm
Larghezza cerchi:30mm Larghezza interna:22mm
Forma del cerchio:A U
Peso del cerchio:415g+/-15g
Mozzi:YOELEO 230 SP CL-DB Ratchet System Hub 52T
o DT Swiss 240 EXP Straight Pull Disc Brake Center Lock
Peso dei mozzi:
YOELEO 230 SP CL-DB Ratchet System Hub 52T: 115g+200g
DT Swiss 240 EXP Straight Pull: 118g+220g
O.L.D:
Anteriore QR*100mm, asse passante 12*100mm o asse passante 15*100mm,
QR*135mm posteriore, asse passante 12*135mm o asse passante 12*142mm
Corpo cassetta: per Shimano 10.11 velocità (contattateci se avete bisogno di distanziali per eseguire 9/10 velocità) / Sram XDR
Raggi: raggi neri Pillar WING 20 Aero
Numero di raggi:anteriore 24H, posteriore 24H
Nipples:Nipples neri Sapim Secure Lock
Peso della ruota:
con mozzo YOELEO 230 SP CL-DB Rachet System 52Tl: 1480g+/-15g
con DT Swiss 240 EXP Straight Pull: 1480g+/-15g
Accessori inclusi:
Raggi extra (2 pezzi)
Estensori valvola (2 pezzi)
Larghezza del pneumatico consigliata: da 28 mm a 50 mm
Compatibilità tubo: Presta
Limite di peso del pilota: 231lbs /105kg
Limite di pressione massima del pneumatico: 90PSI
Garanzia: 3 anni
Certificazione:Approvato dall'UCI
Stiffer, Faster, More Aerodynamic
Throughout the last 10 years, Yoeleo continuously strove to update and improve year over year. Widening rims from 20.5mm to 30mm for road and gravel, creating a simple sealed tubeless rim compatible for both clincher and tubeless setups, going from a V to U shape profile rim are amongst the notable updates. All these updates translate into improved aerodynamics, speed and stiffness. They were achieved using our great team of racers or customers along with advanced aerodynamic research and lab testing.
New 2023 PRO WHEELS
All new, better performance, be faster
YOELEO SAT TECHNOLOGY
1. What is YOELEO SAT technology?
YOELEO SAT technology means to build wheels using rims without spoke holes on tire bed, thus, wheels are built without damaging original carbon weave.
2. What are the advantages of SAT technology?
a. Increase 30% strength to wheels;
b. SAT wheels perform better on bumps and pot holes;
c. Inflation capacity increases 10%;
TUBELESS TECHNOLOGY
Compatible with both clincher and tubeless tires
No rim sealing tapes needed for tubeless tires with Yoeleo SAT technology wheelset
Faster and easier to install tubeless tires
OFFSET RIM DESIGN
Offset wheels are asymmetrically profiled wheels which are different from regular bicycle wheels due to their spoke holes drilled offset from the center of the rim.
Benifits of YOELEO offset wheels are :
1.More durable
The spokes in an offset wheel will be at a higher tension compared to a regular symmetric wheel, so an offset wheel will need less re-truing.
2.Increased lateral stiffness & vertical compliance
Reducing the severity of the spoke angle on the drive side boosts lateral wheel stiffness while also improving vertical compliance for increased control.
3.Wider rims
Wider rim or a wider tire or both, you don’t need to pressure your tires as high as in a narrower one to support your weight. Lower pressure makes the ride more comfortable，can take from 28c-47c tires
U-SHAPED RIM DESIGN
Yoeleo has been developing and continually improving on its wheelset design since 2007. Through relentless design optimization, customer feedback, and research, Yoeleo has developed a highly advanced U-shaped profile that offers numerous advantages. Yoeleo designed rim profiles provide excellent stability in crosswinds while offering industry-leading performance and speed.
FRESH LOOKS, MORE PERFORMANCE
Glossy grayish decals with matte marble carbon-finished design to amp up the visuals of your bicycle.
Clean and sleek rims with no painting and clear coat that reduces the overall weight of the wheels.
Rims now have a textured-surface, which will add more friction in the braking surface for wet and dry conditions.
DISC BRAKE RIM DESIGN
Super Light T800 Carbon Fiber
Nicer Looking without Brake Track
Better Aerodynamic
RATCHET SYSTEM TECHNOLOGY
YOELEO 230 SP Ratchet System Hub 52T
The ratchet system technology with 52T which features high-precision star ratchets, guarantees top performance and reliability. The no-tool concept allows extremely simple and quick maintenance.
STRAIGHT PULL TECHNOLOGY
YOELEO 230 SP Ratchet System Hub 52T
The term Straightpull refers to spokes with no bend at the head. This design allows for an ideal strength to weight ratio when compared to conventional spokes. Due to their more precise alignment and direct trajectory, straight-pull spoke technology creates a stiffer, more responsive wheel.
ANTI BITE GUARD TECHNOLOGY
YOELEO 230 SP Ratchet System Hub 52T
ABG stands for Anti Bite Guard, it is a piece of steel spline fitted on the cassette body, strong enough to significantly reduce or completely remove the problem with bitten/damaged freehubs body by cassette rotational force.
THE FASTEST CARBON WHEELS
Yoeleo carbon wheels perform as well or better than competing brands in independent tests in a variety of conditions
THE FASTEST CARBON WHEELS
Data from test in wind tunnel (tested at 50KM/H)
3 YEARS OR 5 YEARS WARRANTY
Durlable, Afforable, Quality Wheelset We offer 3years quality warranty for the wheels including the hubs by YOELEO 230 SP Ratchet System Hub 52T.
Optional for 5 Years
CRASH REPLACEMENT
We hope you don't need this but if you have a crash, we offer a 30% crash replacement discount on all wheels and spares. Please contact us and we’ll do our very best to help you and ride again ASAP.
YOELEO TEST TEAM - 4MINDPROJECT
4Mindproject is a UCI continental cycling team who attend various UCI races throughout the year. R11/R12 is our team machines.
Factory Tour on Yoeleo Carbon Bike Wheelset
UCI Approved
